Over time, the slides on your toolbox drawers can wear out, making them difficult to open and close smoothly. If you’re experiencing sticking or wobbling, it might be time for a slide replacement. In this step-by-step guide, we’ll walk you through how to replace drawer slides on your toolbox, ensuring that your drawers glide effortlessly once again.

What you’ll need:

Removal

Remove the Drawer

  1. Pull the drawer open as far as it goes.
  2. On the side of the drawer, you should see the slide fully extended. On both sides, there will be tabs that move.
  3. On the right side, lift the tab up while simultaneously pushing the tab down on the left side.
  4. Now you can pull the entire drawer out from the toolbox.
  5. Optional – You may want to remove additional drawers to have more space to work.

Remove the Slide from the Toolbox

  1. Use a a flathead screw driver to wedge between the slide and the side of the toolbox.
  2. Lift up the front of the slide (closest to you) to unlatch.
  3. Then you can pop off the back of the slide.

Each slide has two points of contact with the toolbox.

Remove the Slides from the Drawer

  1. Use a screwdriver to press the little square on inside of the drawer.
  2. While pressing, use a mallet to tab the slide until it unclips.
slide replacement

Installation

Install the New Slides on the Drawer

  1. Match the latches and slide into place.

Install the New Slides on the Toolbox

  1. Connect the back of the slide first by matching it up with the groove.
  2. Snap the front of the slide into place by pressing down.

Reinstall the Drawer

  1. Line up both sides of the slides.
  2. Push the drawer all the way in.

Get your replacement slides here:

Replacing the drawer slides on your toolbox is a straightforward task that can restore smooth operation and extend the life of your tool storage. With the right tools and a little effort, a slide replacement will have your drawers gliding like new. Whether you’re fixing a single drawer or giving your entire toolbox an upgrade, this simple maintenance task is well worth the time.
